Metal Jacketed Gaskets

Metal jacketed gasket Metal Jacketed gasket(MJG)is made from graphite,ceramic,non-asbestos etc.filler covered with thin metal jacket,such as stainless teel,carbon steel,copper etc., special used in sealing spots of heat exchanger,pressure vessel etc. this gaskets highly resistance against blow-out ,suitable for high assembly stress 6200DJ Double Jacketed plain gasket 6200DC Double Jacketed corrugated gasket 6200H DJG for Heat Exchanger 6200S DJG with special shape.

Advantages:

Economical:Metal jacketed gaskets offer a cost-effective sealing solution without compromising on performance, making them an economical choice for various applications.

Easy to handle and install:The robust design of metal jacketed gaskets allows for easy handling and installation, reducing downtime during maintenance and ensuring a secure seal.

Suitable for high temperature:Withstanding high temperatures up to 550°C, these gaskets are suitable for applications involving steam, exhaust systems, and other high-temperature environments.

Suitable for narrow flanges:Their design makes metal jacketed gaskets suitable for sealing narrow flanges, ensuring a tight and reliable seal even in constrained spaces.

Good blow-out resistance:The metal jacket provides additional strength, offering excellent blow-out resistance and enhancing the gasket's reliability under pressure.

Benefits:

Over one-piece gaskets with integral bars,

Lower price - Costs savings 10% to 40%: The one-piece gasket design with integral bars offers substantial cost savings—ranging from 10% to 40% compared to traditional multi-piece gaskets. By simplifying the manufacturing process and reducing the number of components, we provide a more economical gasket solution without sacrificing quality. This makes our metal gasket a cost-effective choice for industries looking to optimize their sealing costs.

Quicker delivery - Less time to manufacture: Our metal jacketed gaskets with integral bars streamline the manufacturing process, allowing for faster delivery times. Fewer parts mean less assembly time, which translates into quicker manufacturing. This is especially beneficial for industries with tight deadlines or critical schedules. With a gasket manufacturer like us, you can rely on prompt deliveries without compromising on product quality or performance.

Technically superior and safer: The one-piece gasket with integral bars is not only technically superior but also safer. With fewer components, there is a lower risk of gasket failure due to poor assembly or defective parts. The seamless design provides a more secure seal in high-pressure and high-temperature environments, ensuring enhanced reliability and safety. This superior technology makes our metal gasket material ideal for demanding industrial applications.

Extra sealing safeguards give a better Gasket,

Longer sealing life - seal independently of the outer ring: Metal jacketed gaskets are designed for longer sealing life. The one-piece design allows the gasket to seal independently from the outer ring, resulting in reduced wear and longer-lasting performance. This feature ensures that the gasket continues to provide a reliable seal over time, reducing the frequency of maintenance or replacements. It’s an ideal choice for industries where reliability and durability are crucial. This extended sealing life makes our metal gasket a cost-effective, long-term solution.

About Us:

Founded and Development

Zhihong Sealing Material Co, LTD was in Cang zhou City, Hebei Province, China. lt covers an area of 20000 square meters and a building area of 2000 square meters. After over 20 years development, we had became one professional manufacturer ofindustrial sealing materials and has the license of import and export. Now we have the fnance department, production department, technology department, quality assurance department,inspection department,foreign trade department and other departments. And we have gaskets, workshop, gasket sheet workshop, braided gland packing workshop.

What We offer

Bythe developing ofour company for over20 years, us Zhihong Sealing Material Co, LTD have full manufacturing lines of industrial sealing products,including industrial sealing gaskets such as non-metal and metal gaskets, compression braided gland packings, So we can service so many different industries such as oil and gas, chemical plants, petrochemical,mining, electronic, power stations, food, cement industries, pharmaceutical, the automotive industry, pipeline & boiler manufacturers and other key industries.

Our Vision and Mission

Zhihong Sealing Material Co, LTD , our success is a result of continually satisfying each of our customers' requirements of high performance sealing products. Our corporate quality policy is committed to offering the highest technology, the best service and the best value. And we had maintained an lSO 9001 quality management system.

Our selling prices will be generally competitive as we believe, however due consideration is always given to providing the most suitable material for the particular applications. Material performance, dependability, available alternatives, technical appraisal and production capability are all areas considered when providing the best possible price for the customer.

FAQ:

1. What is the difference between a one-piece gasket and a traditional multi-piece gasket?

A one-piece gasket with integral bars has fewer components, which reduces costs and manufacturing time

while improving overall performance and reliability. It also enhances safety by eliminating the possibility of

failure from poorly assembled parts.

2. How do metal jacketed gaskets work in high-pressure applications?

Our metal jacketed gaskets are designed to withstand high pressures, with extra sealing safeguards built

into the integral bars, ensuring a tighter, more reliable seal even in extreme conditions.

3. Can I customize the size and material of my metal jacketed gaskets?

Yes, as a custom gasket maker, we offer fully customizable solutions for size, shape, and material

compositionto meet your specific application needs. Simply provide your specifications, and we will

tailor the gasket accordingly.

4. What are the advantages of using a metal jacketed gasket with integral bars?

The integral bar design offers significant cost savings, faster delivery, and superior sealing performance

compared to traditional gaskets. The added safeguards ensure a longer sealing life and independent

sealing from the outer ring.

5. How long do metal jacketed gaskets last?

The metal jacketed gasket design offers a longer sealing life due to its durable materials and the ability to

seal independently of the outer ring, reducing the need for frequent replacements. This is especially

beneficial for high-demand applications.
